Product details
2 Jaw Parallel Gripper, Long Stroke TFH
High-precision guidance, compact structure, reliable and cost-effective. Pinion-and-rack synchronization, multiple air interfaces and mounting options, gripping force maintenance versions -AS/-IS available.
High-precision guidance, compact structure
Reliable and cost-effective long-stroke gripping
Pinion-and-rack synchronization for both jaws
- Fast Delivery
- Quality Assurance
- 24/7 Customer Service
Product Introduction
Excellent performance
1. High-precision guidance with a compact structure — reliable and cost-effective for long-stroke applications.
2. Pinion-and-rack drive keeps both jaws perfectly synchronized.
3. Variety of air interfaces and multiple mounting options.
Gripping force maintenance -AS/IS
The TFH grippers can be equipped with gripping force maintenance, expanded to TFH-AS/IS (AS: closing maintenance, IS: opening maintenance). The spring is used as the holding accumulator, ensuring a minimum clamping force in the event of a pressure drop.
Model and Technical Parameters
| Model | Stroke per jaw [mm] | Closing/ opening force[N] | Min. spring force[N] | Weight [kg] | Recommended workpiece weight[kg] | Closing/ opening time[s] | Repeat accuracy [mm] | Protection class IP |
| TFH-30A-1 | 30 | 750/680 | 2.6 | 3.75 | 0.30/0.30 | 0.05 | 41 | |
| TFH-30A-1-AS | 30 | 840/- | 90 | 2.7 | 3.75 | 0.35/0.35 | 0.05 | 41 |
| TFH-40A-1 | 40 | 1280/1120 | 4.7 | 6.4 | 0.30/0.30 | 0.05 | 41 | |
| TFH-40A-1-AS | 40 | 1560/- | 280 | 4.8 | 6.4 | 0.30/0.40 | 0.05 | 41 |
| TFH-40A-1-IS | 40 | -/1400 | 280 | 4.8 | 6.4 | 0.40/0.30 | 0.05 | 41 |
| TFH-50A-1 | 50 | 2620/2350 | 9.5 | 13.1 | 0.70/0.70 | 0.05 | 41 | |
| TFH-50A-1-AS | 50 | 2970/- | 350 | 9.6 | 13.1 | 0.60/0.80 | 0.05 | 41 |
| TFH-50A-1-IS | 50 | -/2700 | 350 | 9.6 | 13.1 | 0.80/0.60 | 0.05 | 41 |
Selection resource
Compare models in the complete selection manual
Review ordering codes, dimensions and technical specifications for all 15 HYCLAMAVIN pneumatic gripper and robot tool changer families.
